UGS:FUD-7010E-P

Système numérique de mesure de la lumière UV FUD-7010E, Premium

Name: Système numérique de mesure de la lumière UV FUD-7010E, Premium
Brand: Pressure Metrics
SKU: FUD-7010E-P
Price: 4000.00 USD
Availability: InStock

$4,000.00

Promotion Épuisé

Quantité

SPECIFICATIONS

Typically, UV light indicating films are analyzed visually using a color correlation chart. When visual UVSCALE analysis is not enough, or more exact numbers are needed, FPD-7010E analyzes, presents, and reports UV light energy density mapping with more detail and digital precision. Fujifilm’s thoughtful combination of expertly matched hardware and software digitizes the UVSCALE film and outputs digital UV light distribution and mapping. The simple, easy-to-use interface controls everything.

The Premium FUD-7010E system includes:

Fujifilm FUD-7010E software
Perfectly matched scanner
Specialized scanner cover
Calibration sheet
Hand-delivery to your site
Professional installation
4 hours of face-to-face training and UV light troubleshooting at your site by our engineer
All travel expenses are included — there is no additional cost to you
Ongoing discounts on Fujifilm UVSCALE products from Pressure Metrics

The FUD-7010E system is brand-name quality from Fujifilm, and backed by Fujifilm and Pressure Metrics, an authorized Fujifilm distributor.

This is how Pressure Metrics helps you See UV In A Whole New Light℠.

PRODUCT INFO

UVSCALE downloadable resources.

Voir tous les détails

UV in a Whole New Light

Fujifilm UVSCALE ultraviolet light distribution measurement film visualizes UV exposure by color density, changing colors depending on the amount of light it is exposed to. Visual analysis calibration chart is also included in full color

FREE Digital Analysis
Using Fujifilm's official FUD-7010E system, we'll digitize & analyze your exposed UVSCALE film for free ($45 value). Send us your film and we'll email you the results within a few days.

Call (866) 963-2392 to get started.
Compatible with FUD-7010E
The FUD-7010E UV light measurement system digitizes, andalyzes, and reports UV light energy density mapping with more detail and digital precision, all in full color.

See UV in a Whole New Light for FREE.

FAQs

What is UVSCALE used for?

UVSCALE is a color-changing film used to visualize and measure UV light distribution and intensity. It helps identify uneven UV exposure in processes such as UV printing, curing, coating, and bonding applications.

How does it work?

When exposed to ultraviolet light, UVSCALE changes color according to the accumulated UV energy. The darker or more intense the color, the greater the UV exposure. Results can be evaluated visually or through digital analysis for higher precision.

What UV light sources is UVSCALE compatible with?

UVSCALE works with a wide range of light sources, including metal halide, low and high-pressure mercury, and LED-based UV systems, covering a broad sensitivity range from 200 to 7000 mJ/cm².

Can films be reused?

No. Each piece of UVSCALE film is designed for single-use testing to ensure accurate measurement of UV exposure. After exposure, results can be documented or digitally analyzed.

What are common applications of UVSCALE?

UVSCALE is commonly used in UV printing, coating lines, curing systems, and quality assurance environments to verify light uniformity, detect lamp degradation, and optimize curing performance.

Can UVSCALE measure UV light in areas where sensors can’t reach?

Yes. UVSCALE is ideal for confined or complex spaces where electronic sensors or radiometers cannot be positioned effectively, such as within roll-to-roll systems or enclosed UV curing chambers.
