Pressure Metrics
UVSCALE LM Roll – UV Light Measurement Film
UVSCALE LM Roll – UV Light Measurement Film
Couldn't load pickup availability
Tax excl.
UVLM-R270
New product
Fujifilm UVSCALE UV light measurement film roll, low 4-6000 mJ/cm2
Volume discounts
| Quantity | Price |
|---|---|
| 1 | $605.00 |
| 2 | $575.00 |
DATA SHEET
| Manufacturer | Fujifilm – Value From Innovation Since 1936 |
| Manufacturer Part Number | UVL/M-ROLL |
| UV Energy Density Range | Low: 200-6,000 mJ/cm² | Medium: 300-7000 mJ/cm² |
| Sold By | Roll |
| Analysis | Visual and Digital |
| Visual Analysis: Calibration Chart | Included at no charge, full color for easy visual analysis |
| Digital Analysis: Scanning Service | Included at no charge, just call, send in your sample, and we will digitize, analyze, and email you the results (a $45 value FREE) |
| Digital Analysis: Hardware | Compatible with Fujifilm FUD-7010E Digital Analysis & Mapping System |
| Quantity Discounts | Yes – with purchase of 2+ rolls |
| Width | 10.5 in (270 mm) |
| Length | 16 ft (5 m) |
| Thickness | 4 mils |
| Cutting | UVSCALE is easy to cut using sharp scissors or a cutting board. |
| Layers | L: 1-ply, M: 2-ply |
MORE INFO
See UV In A Whole New Light℠. Fujifilm UVSCALE film makes it easy to do UV light measurement with results in vivid color. UVLM roll measures UV light between 200-7000 mJ/cm² (depending on the light source.) UVSCALE works well with metal halide, low and high pressure mercury, and LED light sources. Simply insert the film into the location that you want to measure and operate the equipment under normal conditions. Once exposed to UV light, the film registers UV light energy density with an instant color change. The pressure metrics film may be quickly analyzed with a color correlation chart, which is always included at no additional charge. For greater precision and resolution, UVSCALE is also compatible with the cost-effective FUD-7010E system. We are pleased to offer one free digital image analysis with each purchase: simply send us your exposed film, and we will digitize, analyze, and return to you by email, often within just a few days. You may also request to try UVSCALE in your own environment.
